Sports Light Package Includes:
- One (1) Exclusive Power Bar Bracket with
- Three (3) 75,000 Lumen LED Lights and Visors.
- Power Bar Sports Lights Package ships pre-wired and ready to mount.
- Easy installation or replacement with EZ twist/lock connectors.
Unique Advantages:
- Bracket is pre-wired and is ready to mount and power-up. Reduces installation labor up to 50%.
- LED lights attach easily to Power bar bracket with a waterproof twist/lock connector.
- Low EPA and wind resistance due our exclusive low-profile bracket and light yet powerful LED sports lights.
- Unmatched value includes the entire pre-wired assembly consisting of LED lights, bracket, hardware.
- Mounting versatility allowing Power bar to work on round or square poles made of steel or wood.
- Customization capabilities to suit your needs.
Product Specifications:
LED Fixture:
- Material: Aluminum construction with integrated fins to maximize heat dissipation.
- Color: Black
- Power: 500 Watts/each
- Lumens: 75,000/each
- Lumens/Watt: 150
- Voltage: 120-277 Volt standard. 345-480 Volt option as special order.
- Amps: 4.17 @ 120V/1.81 @ 277V
- Color Temperature: 5000K
- Beam Angle: 45°
- Dimming: 0-10V Dimming Capable. Dimming control not provided (field install).
- UL Listed / DLC Premium / IP66
- Life Expectancy: 50,000 hours
- Weight: 25 lbs. (Each)
Total Power: 1500 Watts
Total Lumens: 75,000 x 3=225,000
Total Amps: 12.51 @120V / 5.43 @277V
Warranty: 5 Years
Power bar bracket:
The power bar bracket is designed and made in the USA from high quality structural steel.
- Finish: Black Powder Coat
- Weight: 32 lbs.
- Total Weight: 107 lbs.
- Max EPA (per AASHTO LRFDLTS-1): 6.04 ft² with 180 mph wind speed (Including Bracket)
