Product Description:
- Pole Top: 2 3/8" tenon is standard. 3" tenon or top cap options are available.
- Pole Shaft: 25 ft. height above ground, Tapered aluminum shaft with 0.138" wall thickness. The pole shaft is constructed of seamless extruded tube of 6060 Series Aluminum Alloy.
- Handhole: 3.35" X 15.75" handhole is located 23.6 inches above ground. Handhole cover with 2 Tamper-Resistant Screws is provided. A ground lug with set screw is located near the handhole opening for proper grounding of the pole.
- Embedment: Embedment length is 5.2 ft. Two wire accesses 180° apart are provided 23.6" below ground line.
- Finish: Dark natural aluminum.
- Warranty: 10 Years.
- Maximum Luminaire Weight: 100 lbs.
- Weight: 90 lbs.
- Foundation design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
- POLE HEIGHT:
- 25 Foot
- INSTALLATION TYPE:
- Direct Burial
- POLE SHAPE:
- Round Tapered
- faq_category:
- aluminum-light-poles
- quick_shipping:
- true
- 10_year_warranty:
- true
- WIDTH OR DIAMETER:
- 3.35 Inch
- WALL THICKNESS:
- 0.138 Inch
- Product Note:
- In-stock!
