Spoke Bracket with 3 Arms at 90 Degrees

Item #
PTB390
  • Dark Bronze - Standard
  • Black Powder Coat (2-3 week lead time) +$19
  • White Powder Coat (2-3 week lead time) +$19
  • Gray Powder Coat (2-3 week lead time) +$19
  • Custom Color - Contact LightMart
$186.00

Get A Free Quote


Product Description:The bottom portion of this bracket is 2-1/2 inch in diameter (inside diameter) allowing it to slip fit over any 2-3/8” tenon regardless of the shape of the pole. Each arm is 2-3/8” in outside diameter allowing any light fixture with a standard 2-3/8” slip fitter to fit over. If you require the bottom portion to fit over a 2-7/8” or 4” tenon, please contact one of our sales engineers so that we can provide you a quote for customizing our brackets. 4 set screws are provided to secure this bracket on the pole.

Arm length can be customized. Surcharges and extended lead-times will apply.

Our pole-top brackets are available with a standard Bronze finish however other powder coat finish options are available for you to select while ordering.

Dimensional Drawing: Spoke Bracket with 3 Arms at 90 Degrees
