Worthington Series, 3 inch Round Aluminum Light Pole Assembly Direct Burial

Item #
80183
$551.00

Get A Free Quote
Product Specifications:
  • Pole Top Options: Open top is standard. Removable top cap or tenon is available as an option. 2-3/8” O.D. aluminum tenon is 4” high and is attached to the pole with 3 set screws.
  • Pole Shaft: 3 inch round straight aluminum with 0.125” wall thickness. Seamlessly extruded from 6063-T6 alloy.
  • Pole Height: Standard above grade pole height is 15 ft. Optional heights are 12, 10 and 8 ft. Custom heights are also available.
  • Decorative Base: 2-piece, clamshell style cast aluminum material. Cast aluminum collar is included for proper fitment of 3” OD pole into the base. 4 stainless steel, tamper-resistant screws are included for attachment.
  • Weight: 17.5 lbs
  • Handhole: 2” X 4” size handhole is located at 12” from the ground line. An aluminum handhole cover with 2 screws is provided. A ground lug with set screw is located near the handhole opening for proper grounding of the pole.
  • Color: Black powder coat.
  • Embedment: Embedment length is 3 ft. for all pole heights. A 1-3/4” X 5 3/4” size slotted opening is provided 18 inches from the ground line fo conduit entry.
  • Maximum Load: Designed to support a light with a maximum weight of 25 lbs.
  • Warranty: 10 Years.
  • Use: To be used only as a light pole with a single light fixture on top.
  • Foundation Design: Foundation should be designed by an engineer familiar with local soil and wind conditions as well as local code where the pole(s) will be installed.
POLE WIND RATING (EPA) with 1.3 Gust Factor POLE LENGTH AND WEIGHT
Pole Height (Above Grade) (ft) 70 mph 80 mph 90 mph 100 mph Embedment (ft) Total Length (ft) Weight (lbs)
8 6.3 4.5 3.0 2.0 3 11 15
10 5.0 3.6 2.4 1.6 3 13 18
12 4.2 3.0 2.0 1.3 3 15 20
15 2.9 2.1 1.4 0.9 3 18 24





POLE HEIGHT:
8 Foot
POLE HEIGHT:
10 Foot
POLE HEIGHT:
12 Foot
POLE HEIGHT:
15 Foot
INSTALLATION TYPE:
Direct Burial
POLE SHAPE:
Round
WIDTH OR DIAMETER:
3 Inch
WALL THICKNESS:
0.125 Inch
